Kodak 9000 3D Extraoral Imaging System

For sale  Kodak 9000 3D Extraoral Imaging System with affordable price USD $ 6500 .00. Please contact us for ordering information. All prices are subject to change without notice, except that prices for an order that have been accepted.

Kodak 9000 3D Extraoral Imaging System

The Kodak 9000 3D is a versatile 3-in-1 extraoral imaging system combining panoramic, cephalometric, and focused-field CBCT (cone-beam CT) scans in a single compact footprint. It integrates smoothly into dental, orthodontic, endodontic, and implant practices seeking high-quality imaging with enhanced efficiency.

Imaging Modalities

1. **Panoramic
   **– Classic full-arch imaging with a variable focal trough, adapting to individual jaw shapes and delivering crisp, true panoramas.

2. **Cephalometric
   **– “One-shot” lateral, frontal, and submento-vertex formats captured in under one second to prevent motion blur.

3. **Focused-Field CBCT
   **– High-resolution 3D scans (voxel size down to ~0.076 mm) in a 50×38 mm field—ideal for localized diagnostics (e.g., single tooth, TMJ).
   Optional volume stitching (up to 85×66×37 mm) covers larger anatomical regions.

Key Benefits

• Low-dose CBCT: Comparable to 1–5 periapical films, following ALARA principles.

• Space-efficient: Requires ~20% less space than the predecessor, thanks to a compact cephalometric module.

• Seamless usability: Auto-switching between modes—no need to handle sensors manually.

• Patient comfort: Open, face-to-face positioning with wheelchair accessibility.

• Intuitive software: Easy-to-learn interface, rapid image reconstruction, and integrated planning tools.

• High professional satisfaction: Rated 4.8/5 by dentists for diagnostic clarity, workflow, ease of use, and patient comfort.

Technical Highlights

Clinical Applications

• Implant planning & guided surgery – visualize bone density and nerve location in high detail.

• Impacted tooth and root fracture assessment – 3D view enables precise diagnosis.

• Orthodontics – efficient tracing and serial cephs; full-cranium formats for orthognathic cases.

• Endodontics – localized high-res CBCT reveals canal morphology and periapical lesions.

Summary

The Kodak 9000 3D offers a comprehensive, low-dose, three-modality imaging solution with exceptional image quality, workflow efficiency, and compact design. Its high resolution (0.076 mm voxel), user-friendly features, and expert validation make it a dependable asset for advanced diagnostic imaging in modern dental practices.
